IT6400 Series Bipolar DC Power Supply / Battery Simulator

The unique bipolar voltage/current output makes IT6400 series can be used as a bipolar power source or a bipolar electronic load. The battery simulating function is especially applicable for development and high speed production testing of portable, battery-operated products. IT6400 has ultrafast transient time less than 20 μs and resolute ion up to 1 nA. Its new designed speed shift mode achieves volt age/current fast rising and without overshoot, the rising time up to 150μs. Meanwhile, the waveform display function let the test be visible and simple. IT6400 series can be widely used in portable battery-operated products test, mobile power pack test, LED test and other fields.

Model                   Voltage           Current

Power

Channel

IT6402

CH1-6V - 0V , 0 - 6V

CH20 - 6V

CH1±2A

CH2±2A

CH112W

CH212W

2

IT6411

±15V/±9V

±3A/±5A

45W

1

IT6411S

-15V~0V0~15V

±0.1 A

1.5 W

1

IT6412

CH1±15V/±9V

CH20~15V/0~9V

CH1±3A/±5A

CH2±3A/±5A

CH145W

CH245W

2

IT6412S

CH1-15V~0V,0~15V

CH20~15V

CH1±0.1A

CH2±0.1A

CH11.5W

CH21.5W

2

IT6431

-15V~ 0V, 0~ 15V

±10 A

150W

1

IT6432

-30V~0V0~30V

±5A

150W

1

IT6432S

-30V~0V0~30V

±21mA

0.63W

1

IT6433

-60V-0V,0-60V

±2.5 A

150W

1

* The above specifications are subject to change without prior notice.

Product Features

♦ Maximum output power of single channel up to 150 W , output voltage max. ±60 V, output current max. ±10A
♦ High performance color LCD display, dual channel output display main interface *1
 Bipolar dual-range output
 Accurate Battery Simulation
 Oscilloscope waveform display (DSO)
 Ultrafast transient response time < 20 μs
 Ultrafast voltage rising time up to 150 μs *2
♦ Current display resolution up to 1 nA
♦ Ultra-small current ripple up to 2 Μa rms
♦ Built-in high accuracy DVM
♦ Variable output impedance
♦ Applicable to portable battery power supplies test
♦ LED test no overcharged current
♦ Relay out function achieves electrical isolation on terminals
♦ High speed AD sampling
♦ List function achieves voltage/current output as programmed
♦ Standard interface LAN/USB/GPIB

*1 IT6412 provide this function
*2 IT6432H stay tuned


Applications

 Portable battery-operated products test
 Mobile power pack test
 Battery protection board test
 Battery test
 LED test
 Power amplifier Test
 DC / DC converter test
 Support fast charge
 Fast charge has become a development trend for mobile phone, tablet PC and other electronic products, the major electronics manufacturers also focus on fast charge. IT6431 battery simulator current output up to ± 10 A, fully meet the market mainstream low-voltage, high current f ast charge test requirements.

Functions and Advantages

Bipolar Output

IT6400 high speed linear DC source provides bipolar output, maximum output voltage of single channel up to ± 60 V, maximum output current up to ± 10 A. IT6400 is with multi-functional and high-performance output, so that it meets various of test needs. IT6412 is a dual-channel bipolar DC source and it is available for easy-shifting dual range output with each channel. Users can switch according to test requirements, one set of IT6412 can finish mobile and charger test independently a single device to complete the test phone and charger, easy to use.


Oscilloscope Waveform Display Function
IT6400 battery cell simulator provides waveform display function based on sample data. The voltage/current waveform is visible or invisible by your option, and can be adjusted by the knob. The graphic on the newly design colorful display can be saved, achieves easy and effective oscilloscope experience.


Battery Simulating Function

With the unique current bipolar design and 0~20 Ω variable output impedance, IT6400 battery simulator power supply is applicable to types of portable battery charge-discharge tests. Simulating the battery charge-discharge features and assist with other tests are also reliable. One equipment, diversified applications.

Options & Accessories

·

AC power cord (accessory)

AC power cord (accessory)

·

CD (accessory)

With user manual and communica...

·

USB

For USB port communication

·

IT-E31220-OO (Optional)

120A/2m/round terminal, a pair...

·

IT-E30615-OO (Optional)

60A/1.5m/round terminal, a pai...

·

IT-E32420-OO (Optional)

240A/2m/round terminal, a pair...

·

IT-E32410-OO (Optional)

240A/1m/round terminal, a pair...

·

IT-E33620-OO (Optional)

360A/2m/round terminal, a pair...

·

IT-E30110-AB (Optional)

10A/1m/Alligator clip - Banana...

·

IT-E30110-BB (Optional)

10A/1m/Banana plug - Banana pl...

·

IT-E30110-BY (Optional)

10A/1m/Banana plug - Y termina...

·

IT-E30312-YY (Optional)

30A/1.2m/Y terminal, a pair of...

·

IT-E30320-YY (Optional)

30A/2m/Y terminal, a pair of r...
