VG-862　PCI Bus-compatible Programmable Video Signal Generator

PCI Bus Board Type Programmable Video Signal Generator

VG-862 is a built-in system type video signal generator for use with a built-in PCI bus. The generator is a special purpose digital output unit equipped with DVI (single link) and LVDS output. Windows standard is the installed software that allows output timing and setting / execution / control of a patterns to be easily accomplished. Full color output of natural graphic images is also possible. Building a compact batch control system into the production line together with a set of various types of inspection equipment demonstrates the powerful business signal source.

･Features

･ Supports various display interfaces
DVI and LVDS output connections are provided.
･ Space-saving
Half-size PCI bus board allows attachment to a compact PC.
･ Broadband output
Timing setting of 2-dot unit accuracy throughout the whole range is possible. Dot clock conforms to DVI 25~165MHz, and LVDS supports 20~85MHz.
･ Windows-supporting software included as a standard package
Editing / registration / execution of timing and patterns are possible by using the installed Windows software.
Also, users may arbitrarily create any software with optional libraries. Library function / parameters are basically the same as in conventional models so that user software created in the past may easily converted.
　
